The Vestra W12 Subwoofer is built to deliver uncompromising bass performance, perfect for any high-fidelity setup as a standalone item or in multiples for the ultimate fully immersive AV experience. The W12 delivers a potent combination of power, precision, and seamless design. Utilising Clever DSP (Digital Signal Processing) enhances customisation, allowing you to fine-tune the bass response to your space.
The Vestra W12’s sealed-enclosure design houses a 12-inch C-CAM (Ceramic-Coated Aluminium Magnesium) high linear-excursion driver featuring triple-layer suspension for greater control and ensuring precise, powerful bass with minimal distortion. Supported by a robust 500-watt Class-D amplifier and a rigid, acoustically optimised enclosure, the W12 delivers deep, impactful lows that remain clear and controlled at all listening levels.
Features
- High linear-excursion C-CAM (Ceramic Coated aluminium Magnesium) driver
- Triple suspension driver
- 500-Watt Class-D Amplifier
- Sealed-Enclosure
- Three EQ pre-set modes
- Stereo unbalanced RCA inputs
- LFE unbalanced RCA inputs
- 12 Volt trigger
- 3.5mm mono jack
| System Format | Active |
| Frequency Response (In-room, -6dB) | 17 — 200 Hz |
| Maximum Usable SPL - Peak (CTA 2010-B, Z-weighted, half-space) | 115 dB |
| Amplifier Output Instantaneous (RMS) | 500 W |
| Amplifier Classification | High-Efficiency Class-D |
| Bass Alignment | Sealed |
| Low Pass Filter Frequency (-6dB) | 32 — 200 Hz |
| Inputs | Stereo Unbalanced RCA LFE Unbalanced RCA 12 V Trigger 3.5 mm mono jack |
| Input Impedance | 47 kOhms |
| Phase Control | 0° & 180° Toggle Switch |
| Equalisation DSP | 3 pre-set modes: Impact, Movie, Music |
| Auto Music Sensing | Auto On: Line Level >3 mV | Auto Standby after 20 mins |
| Mains Input Voltage | Universal Mains, 85 - 265 VAC, 50 - 60 Hz |
| Power Consumption (1/8th Maximum Output) | 120 W |
| Drive Unit Complement | 1x 12" (305 mm) High Linear-Excusion Triple Suspension Driver |
| External Dimensions with all accessories fitted (H x W x D) | 385 x 371 x 401 mm (151/8 x 149/16 x 1513/16") |
| Weight | 18.3 kg |
| Grille | Cloth covered |
| Warranty | 5 years |
