The Vestra W10 Subwoofer is designed for powerful, engaging bass that will bring your favourite music and movies to life - ideal on its own or in multiples for the ultimate immersive experience. The W10 delivers deep, controlled lows with minimal distortion, and its sleek, compact form fits seamlessly into any space. The W10 is the ultimate upgrade for those wanting powerful sound with a minimalist design.
A highly versatile, compact, 10” (254mm) sealed-enclosure subwoofer powered by a potent 250-Watt Class-D amplifier, ideal to be used in multiples or as a single unit within a smaller two- or multi-channel system. The W10 is equipped with a precision-engineered 10-inch C-CAM (Ceramic-Coated Aluminium Magnesium) high linear-excursion driver sat within a robust sealed enclosure, as well as useful DSP (Digital Signal Processing) presets allowing for a certain amount of personalisation within an environment. This ensures the W10 is easy to set up while producing a rich, dynamic performance.
Features
- High linear-excursion C-CAM (Ceramic Coated aluminium Magnesium) driver
- 250-Watt Class-D Amplifier
- Sealed-Enclosure
- Three EQ pre-set modes
- Stereo unbalanced RCA inputs
- LFE unbalanced RCA inputs
- 12 Volt trigger
- 3.5mm mono jack
| System Format | Active |
| Frequency Response (In-room, -6dB) | 19 — 200 Hz |
| Maximum Usable SPL - Peak (CTA 2010-B, Z-weighted, half-space) | 111 dB |
| Amplifier Output Instantaneous (RMS) | 250 W |
| Amplifier Classification | High-Efficiency Class-D |
| Bass Alignment | Sealed |
| Low Pass Filter Frequency (-6dB) | 32 — 200 Hz |
| Inputs | Stereo Unbalanced RCA LFE Unbalanced RCA 12 V Trigger 3.5 mm mono jack |
| Input Impedance | 47 kOhms |
| Phase Control | 0° & 180° Toggle Switch |
| Equalisation DSP | 3 pre-set modes: Impact, Movie, Music |
| Auto Music Sensing | Auto On: Line Level >3 mV | Auto Standby after 20 mins |
| Mains Input Voltage | Universal Mains, 85 - 265 VAC, 50 - 60 Hz |
| Power Consumption (1/8th Maximum Output) | 60 W |
| Drive Unit Complement | 1x 10" (254 mm) High Linear-Excusion Driver |
| External Dimensions with all accessories fitted (H x W x D) | 344 x 330 x 360 mm (131/2 x 13 x 143/16") |
| Weight | 13.3 kg |
| Grille | Cloth covered |
| Warranty | 5 years |
